Geohex Erosion Control System

Turn unstable, muddy, or eroding ground into a solid, permeable surface with our Geohex ground reinforcement pavers. Engineered for heavy-duty performance, this modular grid system locks infill material in place while letting water pass straight through — no more potholes, rutting, or surface runoff.

Key Specifications

• Panel Size: 1000mm (L) x 500mm (W) x 42mm (H) — 2 panels cover 1 full square metre
• Weight: 2.3kg – 2.7kg per paver
• Material: 100% recycled co-polymer polypropylene (Reprolen)
• Load Rating: Up to 1,200 tonnes/sqm when filled, 300 tonnes unfilled
• Water Permeability: 99.7%, virtually eliminating surface runoff

Where It's Used

• Construction Sites: Stabilises heavy vehicle access roads and site thoroughfares; high-visibility SAFETYHEX variant available for exclusion zones
• Farms & Rural Properties: Stops mud build-up around gates, stables, and livestock water troughs
• Sports & Recreation: Protects turf on golf cart paths and greenkeeper access routes
• Home & Garden: Ideal for permeable driveways, walkways, garden edging, and reinforcing slopes over 30°

Why Choose Geohex

• Locks Infill in Place: Keeps gravel, soil, or turf from shifting or washing away
• Safe & Sustainable: Made from post-consumer recycled plastic, chemically inert, and safe around plants, pets, and livestock
• Easy to Install, Easy on the Budget: Panels interlock tightly for compact shipping and a fraction of the cost of poured concrete
